Oropharyngeal Airway

1. Center channel, Guedel type
2. It is used to maintain an open airway, preventing the tongue from covering the epiglottis, which could prevent the person from breathing

Click to Favorites
  • Product details


Oropharyngeal Airway

Airway tube:

-          Center channel, Guedel type

-          Semi-rigid, nontoxic, flexible design

-          Smoothly finished and rounded edges, less oral trauma, maximize patient comfort

-          Smooth airway path for easy cleaning

-          Size identified on the flange end

-          Latex Free

Bite block:

-          Reinforced bite block helps prevent biting of tongue and airway occlusion

-          Color coded for easy size identification

Individual package:

-          With PO pouch Sterile

-          With Paper blister pouch Sterile



Intended use:

-          It is used to maintain an open airway, preventing the tongue from covering the epiglottis, which could prevent the person from breathing. The Guedel airway is indicated in unconscious people only. When a people become unconscious, the muscles in their jaw relax and allow the tongue to obstruct the airway.

-          It is used commonly in pre-hospital emergency care and for short term airway management post anaesthetic or when manual methods are inadequate to maintain an open airway

-          Insertion: the correct size of Guedel airway is chosen by measuring from the middle of the persons mouth to the angle of the jaw. The airway is then inserted into the person’s mouth upside down. Once contact is made with the back of the throat, the airway is rotated 180 degrees, allowing for easy insertion and assuring that the tongue is secured. In children, the airway is inserted right side up, to avoid trauma to the soft tissues.



Oropharyngeal airway- Guedel type

Item No.

Size

Length (mm)

Color code

HTA1101

#000

40

Pink

HTA1102

#00

50

Dark blue

HTA1103

#0

60

Black

HTA1104

#1

70

White

HTA1105

#2

80

Green

HTA1106

#3

90

Yellow

HTA1107

#4

100

Red

HTA1108

#5

110

Light blue

HTA1109

#6

120

Orange
